MARLEY

Marley Wessex Concrete Roof Tiles - All Colours

This product is a call to enquire product. Please call us on 020-3481-1978 for more information.
The option you have currently selected is a call to enquire option. Please call us on 020-3481-1978 for more information or select an alternative option.
Regular price
£2.21 £2.65
Was:
£0.00
Now Only:
£2.21 £2.65
Sold out
Unit price
per
+
✔ This product is eligible for our buy now & pay later scheme - available at checkout (read more)
MARLEY

Marley Wessex Concrete Roof Tiles - All Colours

Product Code: MAR10652S

Designed to shed water efficiently at pitches down to 15° the Wessex interlocking tile has clean, simple lines with a pleasing minimalist style.

All Marley concrete interlocking tiles can achieve an 'A+' rating (the lowest environmental impact) in the Building Research Establishment's Green Guide to Specification.

Advantages:


  • Low pitch solution
  • Minimalist style.
  • Designed to shed water efficiently
  • Can achieve an A+ rating in the BRE Green Guide to Specification


Notes


The effectiveness of the tile or slate to operate at the minimum recommended pitch and lap may be influenced by special circumstances. Guidance on pitch and lap should be obtained from the Technical Advisory Service for the following:


  • Interlocking tiles and slates where the roof slope exceeds 6 metres in length and/or the site is rated to be in a severe exposure category.
  • Double-lap fibre cement slates where the roof slope exceeds 6 metres in length (severe/very severe exposure) and 9 metres in length (sheltered/moderate exposure).


Batten size recommended 38 x 25mm for rafters/supports not exceeding 450mm centres. 50 x 25mm for rafters/supports not exceeding 600mm centres
Battens required 2.9 lin.m/m2 at 75mm headlap. 3.1 lin.m/m2 at 100mm headlap
Cover width 298mm (nominal)
Hanging length 403mm
Headlap 75mm
Material type Concrete
Maximum gauge 345mm
Maximum pitch 44
Minimum pitch 15
Size overall 420mm x 330mm
Sold per pack
Tile coverage 9.7 tiles/m2 at 75mm headlap. 10.4 tiles/m2 at 100mm headlap
Weight of tiling 50 kg/m2 (0.49kN/m2) at 75mm headlap. 53 kg/m2 (0.52kN/m2) at 100mm headlap

For information on delivery costs and more click here.


Description

Designed to shed water efficiently at pitches down to 15° the Wessex interlocking tile has clean, simple lines with a pleasing minimalist style.

All Marley concrete interlocking tiles can achieve an 'A+' rating (the lowest environmental impact) in the Building Research Establishment's Green Guide to Specification.

Advantages:


  • Low pitch solution
  • Minimalist style.
  • Designed to shed water efficiently
  • Can achieve an A+ rating in the BRE Green Guide to Specification


Notes


The effectiveness of the tile or slate to operate at the minimum recommended pitch and lap may be influenced by special circumstances. Guidance on pitch and lap should be obtained from the Technical Advisory Service for the following:


  • Interlocking tiles and slates where the roof slope exceeds 6 metres in length and/or the site is rated to be in a severe exposure category.
  • Double-lap fibre cement slates where the roof slope exceeds 6 metres in length (severe/very severe exposure) and 9 metres in length (sheltered/moderate exposure).




Technical Specifications

Batten size recommended 38 x 25mm for rafters/supports not exceeding 450mm centres. 50 x 25mm for rafters/supports not exceeding 600mm centres
Battens required 2.9 lin.m/m2 at 75mm headlap. 3.1 lin.m/m2 at 100mm headlap
Cover width 298mm (nominal)
Hanging length 403mm
Headlap 75mm
Material type Concrete
Maximum gauge 345mm
Maximum pitch 44
Minimum pitch 15
Size overall 420mm x 330mm
Sold per pack
Tile coverage 9.7 tiles/m2 at 75mm headlap. 10.4 tiles/m2 at 100mm headlap
Weight of tiling 50 kg/m2 (0.49kN/m2) at 75mm headlap. 53 kg/m2 (0.52kN/m2) at 100mm headlap
