MARLEY

Marley Mendip Concrete Roof Tiles - All Colours

This product is a call to enquire product. Please call us on 020-3481-1978 for more information.
The option you have currently selected is a call to enquire option. Please call us on 020-3481-1978 for more information or select an alternative option.
Regular price
£1.16 £1.39
Was:
£0.00
Now Only:
£1.16 £1.39
Sold out
Unit price
per
+
✔ This product is eligible for our buy now & pay later scheme - available at checkout (read more)
MARLEY

Marley Mendip Concrete Roof Tiles - All Colours

Product Code: MAR12338S

A double pantile design with elegant flowing lines, instant visual appeal and exceptional strength.

The Mendip interlocking tile is available in 7 stylish colours, and is a popular choice with discerning specifiers and builders alike.

All Marley concrete interlocking tiles can achieve an 'A+' rating (the lowest environmental impact) in the Building Research Establishment's Green Guide to Specification.

Advantages:


  • Low pitch solution
  • Performs at rafter lengths up to and including 10m
  • Excellent covering capacity
  • Double pantile.
  • Elegant flowing lines.


Notes:

Mendip interlocking tiles will now perform at extended rafter lengths. See guidance below:


  • 15° - 17.5° pitch with a rafter length up to and including 10m will require a 100mm headlap.
  • 17.5° pitch and above with a rafter length up to and including 10m will require a 75mm headlap.


Batten size recommended 38x 25mm for rafters/supports not exceeding 450mm centres. 50 x 25mm for rafters/supports not exceeding 600mm centres
Battens required 2.9 lin.m/m² at 75mm headlap. 3.1 lin.m/m² at 100mm headlap
Cover width 298mm (nominal)
Hanging length 397mm (nominal)
Headlap 75mm
Length 420mm
Material type Concrete
Maximum gauge 345mm
Maximum pitch 90°
Minimum pitch 15° Smooth (100mm headlap). 17.5° Smooth (75mm headlap). 30° Granular (75mm headlap). 25° Granular (100mm headlap)
Size overall 420mm x 330mm
Sold per pack
Tile coverage 9.7 tiles /m² at 75mm headlap. 10.5 tiles /m² at 100mm headlap
Tile nails 70mm x 3.35mm
Weight of tiling 46kg/m² (0.45 Kn/m²) at 75mm headlap. 49kg/m² (0.48 Kn/m²) at 100mm headlap
Width 330mm

For information on delivery costs and more click here.


Description

A double pantile design with elegant flowing lines, instant visual appeal and exceptional strength.

The Mendip interlocking tile is available in 7 stylish colours, and is a popular choice with discerning specifiers and builders alike.

All Marley concrete interlocking tiles can achieve an 'A+' rating (the lowest environmental impact) in the Building Research Establishment's Green Guide to Specification.

Advantages:


  • Low pitch solution
  • Performs at rafter lengths up to and including 10m
  • Excellent covering capacity
  • Double pantile.
  • Elegant flowing lines.


Notes:

Mendip interlocking tiles will now perform at extended rafter lengths. See guidance below:


  • 15° - 17.5° pitch with a rafter length up to and including 10m will require a 100mm headlap.
  • 17.5° pitch and above with a rafter length up to and including 10m will require a 75mm headlap.




Technical Specifications

Batten size recommended 38x 25mm for rafters/supports not exceeding 450mm centres. 50 x 25mm for rafters/supports not exceeding 600mm centres
Battens required 2.9 lin.m/m² at 75mm headlap. 3.1 lin.m/m² at 100mm headlap
Cover width 298mm (nominal)
Hanging length 397mm (nominal)
Headlap 75mm
Length 420mm
Material type Concrete
Maximum gauge 345mm
Maximum pitch 90°
Minimum pitch 15° Smooth (100mm headlap). 17.5° Smooth (75mm headlap). 30° Granular (75mm headlap). 25° Granular (100mm headlap)
Size overall 420mm x 330mm
Sold per pack
Tile coverage 9.7 tiles /m² at 75mm headlap. 10.5 tiles /m² at 100mm headlap
Tile nails 70mm x 3.35mm
Weight of tiling 46kg/m² (0.45 Kn/m²) at 75mm headlap. 49kg/m² (0.48 Kn/m²) at 100mm headlap
Width 330mm
